PP450 – Disc pre-pruner
The Disc Pre-Pruner is designed for mechanical winter pruning of vineyards, ensuring clean and precise cuts with high productivity and reduced operating costs.
It adopts a synchronized pantograph movement system with 4 movements (lift – translation – tilting – arc opening/closing), which allows use in narrow spaces (min. 55 cm) or wide spaces (up to 155 cm), maintaining minimum footprint when closed, ideal also for hillside terrain. The cutting system uses stainless steel discs with serrated profiles, which cut the canes without fraying them.
The electric joystick control manages lifting, translation, tilting and disc opening. The machine requires an oil flow rate of 35 l/min, working pressure of 120 bar and a free return line.
You may also like…
C-305 Independent Hydraulic Power Unit
It's designed to give greater functionality to equipment requiring a hydraulic system, without burdening the tractor's own system. This way, the oil used by the equipment always remains in a closed circuit. Thanks to its cooling system and proper filtration, it allows for maximum performance from all connected machinery.
C-301 Front Ballast Weight Hitch
SKU:
C-301
C-302 Rear/Front 3-Point Hitch
SKU:
C-302
C-306 Vertical Cutting Bar (190 cm)
SKU:
C-306
Related Prodotti
B4 Double Inter-row Tiller
